GE IC695EIS001 转子包括主轴、叶轮、动叶片和联轴器。联轴器。定子包括进汽部分、汽缸、隔膜和定子级联、汽封和轴承等。

The rotor consists of the main shaft, impeller, moving blades and coupling. Coupling. The stator includes the steam inlet section, cylinder, diaphragm and stator cascade, steam seals and bearings.

GE IC695EIS001 涡轮机机电主轴弯曲的原因

1. 汽缸隔热不良。如果汽缸的隔热性能较差，在汽轮机启动和停机时，上下汽缸的温差会很大。在汽轮机启动和停机过程中，上缸和下缸会产生较大的温差。一般情况下，上缸的温度高于下缸的温度，这使得上缸在启动和停机过程中会产生较大的温差。一般情况下，上缸温度高于下缸温度，使得上缸膨胀高于下缸，上缸拱起。

Causes of bending of turbine electromechanical spindles

1. Poor cylinder insulation. If the cylinders are poorly insulated, the temperature difference between the upper and lower cylinders will be large during turbine startup and shutdown. During startup and shutdown of the turbine, a large temperature difference is generated between the upper and lower cylinders. Generally, the temperature of the upper cylinder is higher than that of the lower cylinder, which causes a large temperature difference between the upper cylinder during startup and shutdown. Generally, the temperature of the upper cylinder is higher than that of the lower cylinder, which makes the upper cylinder expand higher than the lower cylinder and the upper cylinder arch.

GE IC695EIS001 由于运行时的强烈振动，会产生动静摩擦和摩擦后产生的热量。由于剧烈的振动摩擦、

摩擦部分的温度非常高，导致材料的屈服强度降低。过高的热应力会导致

轴的热变形，并造成轴向摩擦侧的凸起弯曲，这进一步加剧了温升，导致轴的弯曲增加。轴弯曲加剧。

GE IC695EIS001 Due to strong vibration during operation, dynamic and static friction and heat generated after friction are generated. Due to intense vibration friction,

The temperature of the friction part is very high, resulting in a reduction of the yield strength of the material. Excessive thermal stress leads to

thermal deformation of the shaft and causes raised bending of the axial friction side, which further increases the temperature rise and leads to increased shaft bending. Increased shaft bending.
