Yokogawa AVR10D-Q22020 输入输出模块
横河AAI143-H53是一款脉冲输入/模拟输出模块,兼容横河品牌。它主要用于接收触点开/关、电压脉冲和电流脉冲信号,并可配置在各通道之间,采用双冗余配置。此外,该模块还具有隔离通道,可提供发射机电源等功能。
The Yokogawa AAI143-H53 is a pulse input/analogue output module compatible with the Yokogawa brand. It is mainly used to receive contact open/close, voltage pulse and current pulse signals and can be configured between channels in a dual redundant configuration. In addition, the module has an isolated channel for transmitter power supply and other features.
输入通道数,孤立通道,输入信号线类型:触点开/关,电压脉冲,电流脉冲(可提供变送器电源)输入频率0至10千赫(耐压输入和系统之间:500VAC,持续1分钟最小输入脉冲宽度40毫秒,触点输入继电器触点和晶体管触点的开/关电平,光度:1000或低,氯化:200Ω或低触点容量
Number of Input Channels, Isolated Channels, Input Signal Line Type: Contact On/Off, Voltage Pulse, Current Pulse (Transmitter Power Supply Available) Input Frequency 0 to 10 kHz (Withstanding Voltage Between Input and System: 500 VAC for 1 minute Minimum Input Pulse Width 40 ms, Contact Input Relay Contacts and Transistor Contacts On/Off Level, Luminous: 1000 or Low, Chlorinated: 200 Ω or Low Contact Capacity
输入信号电平,当供电12VDC时:15VDC15mA或更高,24V DC供电时:30V DC 30mA或更高
电压/电流脉冲输入(电流输入转换为电压。)VH(高电手):3至24VDC,VL(低电平):-1至8伏直流电,VH-VL(摆动值):3伏或更高,显示抗药性:1kΩ以下
Input signal level, when supplied with 12VDC:15VDC15mA or higher, when supplied with 24V DC:30V DC 30mA or higher
Voltage/current pulse input (Current input converted to voltage.) VH (high hand):3 to 24VDC, VL (low level):-1 to 8 volts DC, VH-VL (swing value):3 volts or higher, display resistance:1kΩ or less
