NI CDAQ-9171 Compact FieldPoint控制器

该设备配备1个以太网端口，带有10BaseT和100BaseTX以太网接口。一旦发送，控制器可以与另一个cFP-2020、FieldPointcFP-2020精明的控制器或不敏感的系统接口(如FP-16xx和FP-1000进行通信。

The unit is equipped with 1 Ethernet port with 10BaseT and 100BaseTX Ethernet interfaces. Once sent, the controller can communicate with another cFP-2020, FieldPointcFP-2020 savvy controller, or insensitive system interface (such as the FP-16xx and FP-1000.

用户系统上的每个cFP2020都需要11-30VDC控制电源。NI为大多数Compact FieldPoint应用指定了PS-5电源。PS-5提供24V、120W的电压，旨在安装在DIN导轨上。

Each cFP2020 on a user's system requires an 11-30VDC control power supply.NI specifies the PS-5 power supply for most Compact FieldPoint applications.The PS-5 provides 24V, 120W and is intended to be mounted on a DIN rail.

此外，cFP-2020界面自然地将I/O估计值分发到基于Windows的PC，该PC运行FieldPointExplorer、LabVIEW、LabView数据记录和监控模块(LabVIEW DSC)、LabWindows/CVI、Lookout或用于OLE过程控制的应用程序编程客户。(OPC)的用户的决定。此外，它还能与现有的传统框架或可编程逻辑控制器(PLC)框架有效协调。重要的是要记住NIcFP-2020支持LabVIEW实时8.5.1和以前的版本。

In addition, the cFP-2020 interface naturally distributes I/O estimates to a Windows-based PC running FieldPointExplorer, LabVIEW, LabView Data Logging and Supervision Module (LabVIEW DSC), LabWindows/CVI, Lookout, or an application programming client for OLE process Application Programming Client for OLE process control. (OPC) at the user's discretion. In addition, it coordinates effectively with existing legacy frameworks or programmable logic controller (PLC) frameworks. It is important to remember that the NIcFP-2020 supports LabVIEW Real-Time 8.5.1 and previous versions.
