Schneider 140ACO02000 输入/输出模块
140ACO02000 模块具有六种可识别的功能,在模块的正面顶部,您可以看到颜色编码的模块编号以及说明,数字下方是带有8个不同指示灯的LED,保险丝切口区域封闭在带有客户识别标签的可拆卸门中,和现场接线端子板。
The 140ACO02000 module has six identifiable functions, at the top of the front of the module you will find the colour coded module number as well as the description, underneath the numbers are the LEDs with 8 different indicators, the fuse cutout area enclosed in a removable door with a customer identification label, and the field wiring terminal block.
Modicon 140ACO02000 是施耐德电气制造的模拟量输出模块,它是用于离散和模拟I/O 模块的 Modicon Quantum ExoStruxure控制系列的一部分,可以使用UnityPro软件进行配置。
The Modicon 140ACO02000 is an analogue output module manufactured by Schneider Electric as part of the Modicon Quantum ExoStruxure control family for discrete and analogue I/O modules that can be configured using UnityPro software.
140ACO02000 该模块的输入范围为0...25 mA 0...20 mA 4...20 mA,分辨率为0...25 mA : 0...25,000 点0...20 mA:0...20,00点4...20 mA :0...16,000 点(默认)4...20 mA:0...4095点,通道之间没有隔离,它有8个输出字。所需的总线电流为550mA,最大功耗5.0W,可在线修改配置。它符合 UL 508、CSA 22.2-142、e、FM Class 1 Div.标准。2、ATEX 2/22 区认证。
The module 140ACO02000 has an input range of 0... .25 mA 0... .20 mA 4... .20 mA, with a resolution of 0... .25 mA : 0... .25 mA : 0... .25,000 points 0... .20 mA: 0... .20,00 points 4... .20 mA :0... .16,000 points (default) 4.... .20 mA:0... .4095 points, there is no isolation between channels and it has 8 output words. The required bus current is 550 mA, the maximum power consumption is 5.0 W. The configuration can be modified online. It complies with UL 508, CSA 22.2-142, e, FM Class 1 Div. 2, ATEX Zone 2/22 certification.
